FEATURES

• Non blocking Gigabit Ethernet Switch
• Enterprise Class switching functions
• Fully managed L2 solution (L3 upgradable)
• Up to 22x 1000BASE-T Uplinks
• 10/100/1000BASE-T Management Port
• Freescale MPC8544 running at 1 GHz
• 32-bit PowerPC E500 Core
• Double precision embedded scalar and vector floating-point APUs
• Memory Management Unit (MMU)
• Integrated Security Engine

DESCRIPTION

Ultra-Compact High-Density 10/100/1000 Ethernet Routing Switch is 10/100/1000 Ethernet Routing switch provides high performance in a super-compact, super-efficient size. The EMRRS-262G small size, only 1.4″ in height, combines the capacity of physically larger backbone switches with the economy of workgroup switches.
Very high port density means that a single EMRRS-262G Compact Routing can support up to 22 Gigabit Ethernet auto sensing 10/100/1000 Ethernet ports. The EMRRS-262G Compact Routing Switch is the optimal platform for many applications, from the Metro access arena to the Metro edge and enterprise boundaries. Data centers, server farms, wiring closets and other application users can benefit from its uncompromised standards-compatibility (for flawless interoperability), its modular support of various interfaces that guarantees easy upgradeability and scalability, and its feature-rich routing capabilities make the EMRRS-262G a versatile, effective platform for any IP-based service. Copper Gigabit Ethernet provides cost-effective high-speed uplink and cascading capabilities.

The EMRRS-262G includes a1 GHz 8544 PowerPC processor that gives you coolest implementation of a E500 core with plenty of features.
With a requirement as low as 15 Watts [(typ.) for the CPU only] between -40° and + 71°C, it is a major breakthrough for small form factor rugged computers.
Applications targeting Vetronics and onboard UAV which operate on a tight power budget will welcome its innovative design.

Standards

Quality Of Service on all ports (IEEE 802.1p)
Static link aggregation (IEEE 802.3ad) on any port combination
Classic, rapid and multiple spanning tree support (802.1D, 802.1w, 802.1S)
Full duplex operation and flow control on all ports (IEEE 802.3x)
Static MAC filtering, port authentication (IEEE 802.1X)
Layer 2 multicast services using GARP/GMRP (IEEE 802.1p)
VLAN support including VLAN tagging (IEEE 802.3ac), dynamic VLAN registration with GARP/GVRP (IEEE 802.1Q) and protocol based VLANs (IEEE 802.1v)
Double VLAN tagging, port mirroring, IGMP snooping
Routing Protocols (Optional) Include OSPFv2, RIPv2, VRRP, VLAN routing and DHCP relay
Switch Management Fully managed L2 switch via SNMP, TELNET, CLI Out of Band (front panel FE) or In-band via Fabric

ENVIRONMENTAL CHARACTERISTICS

TEMPERATURE

Industrial Grade: 0 – +55 oC
Rugged Grade: -40 – +71 oC
Non Operating: -40 – +85 oC

ALTITUDE From S.L. to 45,000 FT operation & non-operation

HUMIDITY

Operating/Storage 95% at 35OC

VIBRATION

Transportation Loss Cargo per MIL-STD-810F, Method 514.4. fig 514.5C-1
Functional Aircraft vibration per MIL-STD-810F, Method 514.4. based on fig 514.4C-8 and 514.5C-9
Endurance Aircraft vibration per MIL-STD-810F, Method 514.4. based on fig 514.4C-8 and 514.5C-9

SHOCK

Operating: MIL-STD-810E Method 516.4 Procedure I. (20g for 11msec)
EXPLOSIVE MIL-STD-810F, Method 511.4. Porc. I
EMI/RFI MIL-STD-461E
DRIP MIL-STD-810F Method 506.4 Proc. III
DUST MIL-STD-810F,Method 510.4, Proc. I

PHYSICAL CHARACTERISTICS

SIZE 2.8” H x 10” W x 14.25” D
WEIGHT ~2.5 Kg.
POWER 20 – 30 VDC
MIL-STD-704E
